| Characteristic | 1.1 | Style NO |
|
| CPD08A( Two-Stages Standard Mast ) | CPD12A(Two-Stages Standard Mast) | CPD12A-(Three stages) |
| 1.2 | Power Type |
|
| Electric |
| 1.3 | Drive |
|
| Operator Compartment |
| 1.4 | Rated load capacity | Q | kg | 800 | 1200 | 1200 |
| 1.5 | Load centre distance | c | mm | 400 |
| 1.6 | Front overhang | x | mm | 313 |
| 1.7 | Wheel base | y | mm | 1150 |
| Weight | 2.1 | Weight(including accumulator ) |
| kg | 1630 | 2030 | 2180 |
| 2.2 | Gross Axle Weight, Drive side/Steering Bearing side |
| kg | 2020/410 | 2710/520 | 2880/500 |
| 2.3 | Unloaded Axle Weight, Drive side/Steering Bearing side |
| kg | 735/895 | 765/1265 | 940/1240 |
| Wheel | 3.1 | Tyres type |
|
| Solid Rubber |
| 3.2 | Drive Wheel |
|
| 5.00-8 |
| 3.4 | Steering Wheel |
|
| 3.50-5 |
| 3.5 | Tyres Quanity，Drive Wheel/Steering Wheel |
|
| 2/2 |
| 3.6 | Tread, drive side | b10 | mm | 790 |
| 3.7 | Tread, Steering side | b11 | mm | 246 |
| Size | 4.1 | Free Lift Mast Height | h1 | mm | 1755 | 2005 | 2055 |
| 4.2 | Free Lift Height | h2 | mm | 0 | 0 | 1480 |
| 4.3 | Lift Height | h3 | mm | 2500 | 3000 | 4500 |
| 4.4 | Mast Extended Height | h4 | mm | 3317 | 3817 | 5317 |
| 4.5 | Lowered Fork Height ( Forks are at their lowest position) | h5 | mm | 35 |
| 4.6 | Fork Tilt Angle, Forward Tilt/Back Tilt | α/β | ° | 3/5 |
| 4.7 | Falling Object Prtevtive Structure Height | h6 | mm | 1960 |
| 4.8 | Seat Height | h7 | mm | 965 |
| 4.9 | Pedal Height | h8 | mm | 380 |
| 4.10 | Overall Length | L1 | mm | 2640 |
| 4.11 | Frame Length(not including fork) | L2 | mm | 1660 |
| 4.12 | Overall Width | b1 | mm | 920 |
| 4.13 | Fork size | l/e/s | mm | 950/100/35 |
| 4.14 | Fork Outside Width | b5 | mm | 300~766 |
| 4.15 | Min Ground Clearance | m1 | mm | 27 |
| 4.16 | Min Turning Radius | Wa | mm | 1540 |
| 4.17 | Min 90 Turning Aisle | Ast | mm | 2655+200 |
| 4.18 | Pallet size 1000×1000 90 Turning Aisle | Ast | mm | 2855+200 |
| Noise | 7.1 | Noise |
| dB(A) | ≤75 |
